Product Information :
Name :
503221 PSEN 2.2p-21 / PSEN 2.2-20 PilZ @ SRINUTCH Category :
- การบริการต่าง ๆ, การซ่อมบำรุง
Sub - Category :
- Repair and Maintenance
Brand :
พิลซ์ Model :
503221 PSEN 2.2p-21 / PSEN 2.2-20 PilZ @ SRINUTCHProduct Type :
- สินค้า, ผลิตภัณฑ์
Short Description :
Brand : PilZ
PSEN Magnetic Sensor
Type : PSEN 2.2p-21 with PSEN 2.2-20
Part No.: 503221
Supplier : Srinutch Components Co.,Ltd.
Website : www.pilz.tk
Email.: pilz@hotmail.co.th
Spec. คลิกที่เอกสารแนบ + ไฟล์เอกสาร (ด้านล่างค่ะ) Product Detail :
Magnetic safety switch PSENmag for electronic relays - Technical features
| Description | Download | Accessories |
| PSEN 2.2p-21/PSEN2.2-20/LED/8mm 1unit Product number: 503221 |
 |
||
| Product version: | 1.1 |
| Approvals: | CE, cULus Listed, TÜV, ECOLAB |
| Sensor principle: | magnetic |
| Number of N/O: | 1 |
| Number of N/C: | 1 |
| Max. current of safe contacts: | 0.01 A |
| Connection type: | M8, 4pol. male |
| Switching voltage: | 24 V |
| Type of switching voltage: | DC |
| Assured switching distance: | 8.0 mm |
| Assured release distance: | 26 mm |
| Protection type, housing: | IP65 |
| Status indicator: | With LED |
| Design: | Round |
| Depth dimension: | 44.9 mm |
| Gross weight: | 63 g |
| Net weight: | 55 g |
| Ambient temperature: | -25 - 70 °C |
