Product Information :
Name :
774139 PilZ PNOZ e3.1p aT SRINUTCH ThailanD Category :
- คอมพิวเตอร์และอุปกรณ์ ซอฟแวร์ ฮาร์ดแวร์
Sub - Category :
- ซอฟต์แวร์อุตสาหกรรม
Brand :
PilZ - SRINUTCH Model :
774139 PilZ PNOZ e3.1p aT SRINUTCH ThailanDProduct Type :
- สินค้า, ผลิตภัณฑ์
Short Description :
Brand : PilZ
Type : PNOZ e1.1p24VDC 2so
Part No.: 774133
Supplier : Srinutch Components Co.,Ltd.
Website : www.pilz.tk
Email.: pilz@hotmail.co.th
Spec. คลิกเอกสารแนบ + ไฟล์เอกสาร (ด้านล่างครับ)
Product Detail :
Safety relay PNOZelog - E-STOP, safety gates, light grids - Technical features
| Description | Download | Accessories |
| PNOZ e3.1p 24VDC 2so Product number: 774139
|
 |
||
| Product version: | 3.8 |
| Approvals: | CE, cULus Listed, TÜV, CCC |
| Category in accordance with: | EN 954-1 |
| Application options: | Safety gate monitor, Non-contact safety gate monitor, Mechanical safety gate monitor |
| Operating modes: | Single-channel, Automatic reset, Dual-channel, Detection of shorts across contacts, Start-up testing, Monitored manual reset, without detection of shorts across contacts, Self test, with AND input, With OR input |
| Standards: | DIN V VDE 801-1/A1, EN 60204-1, EN 954-1, VDE 0113-1, VDE 0116 |
| Supply voltage: | 24 V |
| Supply voltage type: | DC |
| Terminal type: | Screw terminal |
| Terminal style: | Plug-in |
| Cat. inst. saf. contacts: | 4 |
| Number of instantaneous safety outputs: | 2 ST |
| Number of test pulse outputs: | 2 |
| Number of auxiliary outputs: | 1 |
| Width dimension: | 22.5 mm |
| Height dimension: | 94.0 mm |
| Depth dimension: | 121.0 mm |
| Gross weight: | 146 g |
| Net weight: | 128 g |
| Ambient temperature: | -10 - 55 °C |
